Description
Multi-Pressure BioAerosol Sampler
APPLICATION:
Mode 1: Sampling before decompression
- No damage to microorganisms by drop in pressure
- Automatic sampling
- Automatic decompression release
Mode 2: Sampling after decompression
- High compatibility
- Automatic sampling
- Accurate sampling
SPECIFICATIONS:
Mode 1 (Sampling Before Decompression), Mode 2 (Sampling After Decompression)
- INLET RELATIVE PRESSURE:1-8bar
- FLOW RATE:Mode 1 (Sampling Before Decompression): 10-100LPM (with pressure) ±4%
Mode 2 (Sampling after decompression): ≥2LPM (atmospheric pressure)
- SAMPLING VOLUMES:Mode 1 (Sampling Before Decompression): 20-9999L
- HIGH PRESSURE SAMPLING HEAD DIMENSIONS:Ф140mmx230(H)mm
- HIGH PRESSURE SAMPLING HEAD WEIGHT:5kg (3.3lbs)
Mode 3 (Environmental Sampling)
- FLOW RATE ACCURACY:100L/min±2.5%
- ZONE:Over 20000 locations
- SAMPLING VOLUMES:1-9999L, 6 default volumes
- SAMPLING HEAD:Φ0.60mm*280holes
- PETRI DISH: Ф90-100mm
Common Specification:
- GAS TYPE:Air, N2, CO2, O2, Ar and other inert gases (for non-flammable and non-explosive area only)
- INLET DIAMETER:ID: 5mm, OD:8mm
- OUTLET DIAMETER:ID: 6mm, 8mm, 12mm, 14mm, 16mm, 20mm selectable or silencer
- DIMENSIONS (H×W×D):264x180x140mm (with foot mat)
- WEIGHT:46kg (12lbs)
- EXTERNAL SURFACE:Anodized aluminum
- POWER:24 V±10% AC adapter
- BATTERY:8V, 6800 mAh, rechargeable Lithium battery, running for over 6 hours
- STORAGE:60,000 sets of sample records (mode 1: 20,000 sets, mode 2: 20,000 sets, mode 3:20,000 sets)
- DISPLAY:5″ LCD touch screen
- LANGUAGE:Chinese, English
- CALIBRATION FREQUENCY:Recommend at least once a year
- OPERATING CONDITIONS TEMPERATURE:5°C-30°C, relative humidity up to 80%
- STORAGE CONDITIONS TEMPERATURE:0°C-40°C, relative humidity up to 80%
- SAFETY:EN 61010-1:2010, EN 61326-1:2013, EN 61326-2-2:2013,EN 61000-6-1:2007, EN 61000-6-3:2007+A1
- WARRANTY:2 years after activation
